IRG 509 System: Indoor / Outdoor IR System


Indoor / Outdoor IR System 509

The Active Infrared Security System IRG-509 is designed to operate  indoor and outdoor.  This technology offers a proven track record and may be employed in challenging applications unmatched by other sensor technologies. The scientifically developed optics and electronics  guarantee maximum performance and system longevity.

Key Benefits:

  • Interior and Exterior Applications
  • Multiple Beam Options, Scalable to Customer Needs from 20 cm to 385cm
  • Environmental Class IP65
  • Detects Adversaries at Any Speed (crawling, running, jumping, and rolling)
  • Insusceptible to Sunlight or other Light Sources and Changes in Temperature
  • Performance Rating  > than 99.8%
  • Various Types of Tower Configurations:  From 20 cm to 365 cm Height
  • Clear or Black Anodized Powder Coated in RAL-Colors
  • Custom Designed Mounting Options
  • Integrate to Existing or New Security Systems
  • Precision Alignment Utilizing Advanced Adjustment Device IRG-100-A-L
  • Minimum Maintenance

System Features

  • Active Infrared Sensor
  • Detection Range: Indoor up to 325 feet and Outdoor up to 230 feet
  • IR-beam: Wave length 890nm, Adjustable 25° Horizontal, and 12° Vertical
  • Power Supply: 12 - 24 VDC
  • Alarm Trigger Delay: 25 to 500ms
  • Alarm Relay Signal: 1.5 seconds
  • Detection Performance greater than 99.8%
  • EMC and EMI Protected
  • Low Nuisance and False Alarm Rate (NAR / FAR)
  • Tamper-proof
  • Dimensions one-beam system:  220 x 40 x 40 mm (H x L x W)
  • Operating Temperature:  Interior use: 50°F to 167°F Exterior use: -22°F to 167°F (using additional  heating element IRG-1xx)
